Output Equation of Transformer

Output Equation

The output equation of transformer in KVA is to be related with its main dimension is called output equation.

Read Also

Output Equation of an A.C. Machine

Let,

Q = Output, KVA

ϕ_m = Main flux, wb

Bm = Maximum flux density

Ai = Net core area

Aw = Net window area

Agi = Gross (iron) core section

D = Distance between core centers

d = Diameter of circumscribing circle

Kw = Window space factor

f = Frequency

Et= Emf per turn

T_p & T_s = Number of primary & secondary turns

I_p & I_s = Primary & secondary currents

V_p & V_s = Primary & secondary voltages

a_p & a_s = Primary & secondary conductor section

Li = Mean length of flux path in iron

Lmt = Length of mean turn of transformer winding

Gi = Weight of active part of iron

Gc = Weight of copper

Pi = Specific core losses

Pc = Specific copper losses

Output Equation of Single Phase Transformer
